Cnc Router
| Model | QN1212 ATC cnc router |
| Working size | 1200*1200*300mm |
| X axis | 1200mm |
| Y axis | 1200mm |
| Machine table | Vacuum table with2 zones |
| Spindle | 6.0kw atc spindle,24000rpm |
| Spindle dust shoe | Yes |
| Driver motor | Leadshine servo motor1500w |
| Inverter | Fuling inverter |
| Control system | Taiwan LNC 4 axis control system |
| Linear rails | linear square rails imported from taiwan |
| Z axis transmission | TBI ball screw transmission |
| Transmission | Rack and pinion drive |
| Auto Tool sensor | Yes |
| Limit switch | Yes |
| Auto Oiling system | Yes |
| Rotary axis | Yes ,100mm diameter,1200mm length |
| Vacuum pump | Two sets 2.2kw air recycle vacuum pump |
| Voltage | 220v,single phase,50/60HZ |
| Machine frame | Thicken steel welded ,heavy duty design |
| Net weight | 900KG |
| Gross weight | 1000KG |
