Fiber laser marking machine
| UV 5w laser marking machine | ||
| Item No. | QN5W UV laser marking machine | |
| Power | 5W | |
| Laser Wavelength | 355nm | |
| Marking Range | 200mm×200mm | |
| Marking Speed | ≤8000mm/s | |
| Minimum Character | 0.2mm | |
| Rotary axis | Yes,160mm diameter | |
| Minimum Line Width | 0.015mm | |
| Repeat Accuracy | ±0.001mm | |
| Power Stability | <5%rms | |
| Marking depth | 0.3mm | |
| Laser Beam Quality | M2＜1.2 | |
| Repeat Frequency | 20KHz-80KHz | |
| Cooling System | Air cooling | |
| Operating Temperature | 15-35℃ | |
| Power Supply | 110V/50Hz | |
| Supporting format | BMP, GIF, JPG, PCX, TGA, TIFF, PLT, CDR, DMG, DXF etc. | |
| General Power | 0.5KW | |
| Machine dimension | 890mm X 520mm X 860mm | |
| Net Weight | 80KG | |
| Machine standard parts |
5W Gain laser producer galvanometer scanning system EZCAD software High temperature resistance Aluminum decorated appearance laser control card vibrating mirror USB interface Rotary axis |
|
