1000w 1500w 2000w fiber laser cleaning machine

Release Time:2023-04-06 11:28 Reading Times:

1000w 1500w 2000w fiber laser cleaning machine

Machine Descriptions:
laser cleaning machine is the new generation of safe, high efficiency, energy saving, environment-friendly metal laser cleaning equipment, using handheld swing cleaning head, touch screen and button control, combined with the advanced integrated control system, the precision CNC fiber laser cleaning machine is assembled. It meets the cleaning requirements of complex shapes and fine positioning in the industrial processing field, and achieves higher cleanliness cleaning effects and lower overall cost production benefits.

New industrial laser cleaning machine is using surface decontamination capability of laser, using optical fiber transmission guide, so that cleaning can be in different position, the cleaning of different parts of an efficient, green, advanced cleaning technology, compared with chemical cleaning, without any chemicals and cleaning liquid; compared with mechanical cleaning, no grinding no stress, no supplies, minimum of matrix damage (artifacts and paintings, for a wide range of cleaning) (nuclear pipeline cleaning); the applicable object of the industrial laser cleaning machine is also more widely, to remove rust and paint, in addition to dirt, wafer surface treatment; And the cleaning degree of the handheld laser rust remover is high (to remove nano particles, the following pollution) technology has been applied in various fields (mold cleaning, cleaning and coating fighter)

Main Features:

1. Accurate laser cleaning for exact position and precise size.
2. 2. Widely applied in flat,curved and three-dimensional surface for work piece of elastic material and plastic with very small and deep holes.
3. 3. Flexible operation for work pieces with complicated geometric construction can be realized by mechanized or hand-held laser cleaning head.
4. 4. No maintenance and no consumables,dust-free,no chemicals,no pollution.
5. 5. Non-contact cleaning and no damage for substrate Extremely.
6. 6. Low cleaning cost and High cleaning efficiency.

Machine Application:
Handheld laser cleaning machine uses high-frequency and high-energy laser pulses to irradiate the surface of the work piece, so that the surface oil, rust or coating evaporates or peels instantly, and effectively removes the surface attachment or surface coating of the cleaning object at a high speed, so as to achieve the cleaning of the object. It is characterized by no damage to the part matrix, no consumables, energy saving and environmental protection.

Technical specification

Machine Name

Handheld Continuous Fiber Laser Cleaning Machine

Laser Power

1000W 1500W 2000W

Laser Wave Length

1080nm

Laser Source

Raycus /MAX/JPT / IPG

Fiber Length

10M

Cooling Mode

Water cooling

Application

Rust cleaning, Surface Paint Cleaning

Cleaning Width

50MM

Whether anti-high reflection

Yes

leaning Materials

Metal Rust Oil Dust Coating

Working Voltage

AC220V / 50Hz / 60HZ AC380V 50Hz/60Hz

Package Size

162CM L *70CM W*144CM H

Gross Weight

320KG
